RRP £6,899
Ride the evolution of the ultimate trials machine.
Four-stroke engine
The Cota 4RT’s lightweight, fuel-injected, four-valve 258.9cc four-stroke engine delivers the smooth control – and power.
Top-flight protection
The bash plate is shaped to give maximum protection to engine underside and front lower frame rails. It’s also the same design as used by the Montesa World Championship machine and constructed from identical lightweight aluminum, maintaining thickness with improved strength.
Higher performance
The Montesa 260R is now equipped with the same muffler as the Cota 4RT 301RR. This new exhaust gives more power at mid and high range.
Front and rear SHOWA suspension
Ground clearance is set at 310mm and the high-quality 39mm diameter SHOWA front fork features 158mm stroke. Also, the rear SHOWA shock operates through Pro-Link. Both front and rear suspension are adjustable for spring preload and compression damping.
New aluminium side stand
The lightweight triangular-section forged aluminium side stand from the sister model Cota 301RR is inherited. It mounts close to the engine and tucks neatly underneath the swingarm well out of harms way.
The Montesa Cota 4RT began a revolution back in 2006 with the all-conquering power and torque delivery of its four-stroke engine. Always at the pinnacle of competition, and constantly evolving, the 4RT is the ultimate trials machine. This new 2023 model features a stand-out fuel-tank painted in Montesa’s heritage Red color.
It’s all about quality
The Cota 4RT is carefully manufactured at Montesa Honda’s Factory in Barcelona, northern Spain. Each machine is meticulously assembled with every part checked and rechecked for the highest quality required from a Montesa, and the function of a championship-winning tool.
Ready to go to the top?
If you want to take your competitive riding to the next level the Cota 4RT is primed and ready. Its twin-spar aluminum frame, suspension and strong engine are designed to find grip and drive in the face of what seems impossible. And a host of detail improvements – many inspired directly by the World Championship machine – plus sharp new decals keep the Cota 4RT firmly where it belongs. At the very top. Pictures show motorcycle version with Optional Race Kit and LED headlight. Both items are intended for competition use only. Visit your Montesa dealer for more information.
The art of true balance
A breath-taking climb strewn with wet, vertical rock faces. Or a gnarled descent over moss-covered tree roots. Competitive trials offer perhaps the most severe test of a motorcycle and rider – and it’s what we make the Cota 4RT 260R for.
Bore × Stroke (mm) | 78 x 54.2 |
Carburation | Electronic fuel injection PGM-FI |
Compression Ratio | 10.5 : 1 |
Engine Displacement (cc) | 258.9 |
Engine Type | Single, 4-stroke, 4 valves, SOHC, liquid cooled |
Starter | Kick |
Brakes Front | 185 × 3.0 mm hydraulic disc with 4-piston caliper and sintered metal pads |
Brakes Rear | 150 × 3.0 mm hydraulic disc with 2-piston caliper and sintered metal pads |
Suspension Front | 39 mm SHOWA telescopic fork with pre-load, rebound and compression adjustment. 158mm stroke |
Suspension Rear | Pro-Link system, R16V shock with compression and rebound adjustment. 170 mm stroke |
Tyres Front | 80/100 21 (Dunlop) |
Tyres Rear | 120/100 R18 (Dunlop) |
Wheels Front | Aluminium rims / wire spokes |
Wheels Rear | Aluminium rims / wire spokes |
Battery Capacity (VAh) | 23° |
Dimensions (L×W×H) (mm) | 2020 × 840 × 1135 mm |
Frame type | Diamond, aluminium twin spar |
Fuel Tank Capacity (Litres) | 1.8 litres |
Ground Clearance (mm) | 335 mm |
Seat Height (mm) | 650 mm |
Trail (mm) | 63 mm |
Wheelbase (mm) | 1,320 mm |
Clutch | Wet, multiplate with coil springs |
Final Drive | Roller chain |
Gearbox | 5-speed |
Ignition System | Electronic, digital transistor |
In order to reserve this Montesa Cota 4RT 260R, you can place a fully refundable deposit of £99. Simply click on the the button below to proceed via a secure, one time and fully refundable payment of £99.
